High Efficiency Jaw Rock Crusher 75kw 300r/Min Speed For Crushing
Stone
Product Description:
The XCEX series European version jaw crusher is a new generation
product that has been successfully developed using finite element
analysis based on decades of traditional jaw crusher design and
manufacturing experience. Compared with traditional jaw crushers,
the XCEX series jaw crushers pay more attention to details in
design and manufacturing, using high-strength materials and
manufacturing processes. They have advantages such as higher
structural strength, higher equipment reliability, larger crushing
ratio, higher output, and lower overall costs.
Jaw Rock Crusher is a kind of fine crushing machine, which is
mainly used for crushing medium hardness materials such as rocks,
building materials and ore materials. It is mainly composed of
frame, eccentric shaft, large pulley, flywheel, side guard plate,
bracket, bracket back seat, adjustable gap screw, reset spring,
fixed jaw plate and movable jaw plate. The materials are crushed by
the squeezing force between the two jaw plates. Its capacity is
20-105TPH, and it has a high efficiency and speed of 300r/min, with
a power of 75kw. The jaw rock crusher is mainly made of
high-quality steel, manganese steel and high manganese steel, which
ensures its durability and strength. It is an ideal choice for
coarse crushing operations.
Technical Parameters:
| Parameters | Specifications |
|---|
| Primary Crushing Equipment | × fine crushing machine |
| Jaw Crusher Machine | Jaw Rock Crusher |
| Weight | 11.6t |
| Speed | 300r/min |
| Power | 75kw |
| Efficiency | High |
| Capacity | 20-105TPH |
| Material | Steel, Manganese Steel And High Manganese Steel |
Applications:
BENO XCEX3013 Jaw Rock Crusher
Feed particle size: 0-250mm.
Production capacity: 20-105t/h.
Application fields: various industries such as mining, smelting,
construction, highways, railways, water conservancy, and chemical
industry.
Applicable materials: granite, marble, basalt, limestone, quartz
stone, river pebble, iron ore, copper ore, etc.
This BENO XCEX3013 Jaw Rock Crusher is a primary crushing equipment
designed for use in a wide range of applications. It has been
certified by CE and ISO9001, and is available for a minimum order
quantity of 1. The price ranges from USD 23,835.62-28,064.52, and
the delivery time is 30-90 days. Payment terms include T/T, L/C,
and the available supply ability is 800 sets/year. It has a
capacity of 20-105TPH and a speed of 300r/min, with a power of 75kw
and a weight of 11.6t. The material used is steel, manganese steel
and high manganese steel.
This Jaw Rock Crusher is suitable for various sectors such as
mining, smelting, construction, highway, railway, water
conservancy, chemical industry, and metallurgy. It is suitable for
primary crushing of various rocks and ores, and is highly
efficient, energy-saving, and environmentally friendly. BENO
XCEX3013 Jaw Rock Crusher is a great choice for primary crushing
equipment.
Customization:
BENO XCEX3013 Jaw Rock Crusher is a reliable concrete jaw crusher
and the primary crushing equipment for a variety of ores and rocks.
It has a Certificate of CE and ISO9001, and a minimum order
quantity of 1. The price is USD 23,835.62-28,064.52. The package is
simple. The delivery time is 30-90 days. We accept payment by T/T
and L/C. We have the capacity to supply 800 sets/year. The speed is
300r/min, and the weight is 11.6t. The power is 75kw. BENO XCEX3013
Jaw Rock Crusher features high efficiency and is perfect for
primary crushing.
Advantages of customized production:
Durable structure: The rack can be divided into two types: welded
and assembled for small and medium-sized specifications, and
assembled for large specifications.
Superior cavity design: Symmetrical "V" shaped cavity design, with
a large inclination angle, large stroke, and reasonable rotation
speed of the elbow plate, resulting in larger feed particle size,
higher output, more uniform particle size, and reduced jaw wear.
Design of movable jaw guard: A heavy-duty guard is installed above
the movable jaw to avoid material impact and effectively protect
the movable jaw body and its internal bearings from damage.
Support and Services:
Jaw Rock Crusher Technical Support and Service:
- Installation and maintenance services
- Troubleshooting and problem solving
- Technical advice and guidance
- Spare parts and replacement parts
- Product training and education
FAQ:
Q:
How to reduce the loss of jaw crusher teeth?
A:1. Choose appropriate tooth plate materials: Choose materials with
good wear resistance and impact resistance to make jaw crusher
teeth, such as high manganese steel, chromium molybdenum alloy
steel, etc. These materials have high wear resistance and impact
resistance, which can effectively reduce the wear of the gear
plate.
2. Regular inspection and adjustment of the ore discharge port: The
wear of the tooth plate of the jaw crusher is related to the size
of the ore discharge port. Properly adjusting the size of the
discharge port of the equipment can avoid excessive wear of the
tooth plate due to the small discharge port. Regularly inspect and
adjust the discharge diameter of the jaw crusher to ensure that the
equipment is working in its optimal state.
3. Correct operation and maintenance: Follow the operating
procedures of the jaw crusher to avoid damage to the toothed plate
caused by improper operation. Regular maintenance and upkeep of
equipment, including checking for tooth wear, adding lubricating
oil, etc. Replace damaged gear plates in a timely manner to ensure
the normal operation of the equipment.
