High Efficiency Cone Gravel Crusher 22kw To 30kw Limestone Stone Making Equipment

Ask Lasest Price
Brand Name :	BENO
Model Number :	XCLA-1800
Certification :	CE, ISO9001
Price :	USD 51,780.82-60,967.74 one set
Payment Terms :	L/C, T/T
Supply Ability :	500 sets / year
Delivery Time :	30 days

Add to Cart

Product Details
Company Profile

High Efficiency Cone Gravel Crusher 22kw To 30kw Limestone Stone Making Equipment

Limestone Crushing Cone Crusher Low Vibration Stone-Making Equipment

Equipment Description

Based on the traditional cone crusher, the mechanical Cone Crusher is an equipment that improves the technical principle of the equipment according to the crushing characteristics of the cement industry. Mechanical Cone Crusher has the characteristics of low speed operation, high efficiency and environmental protection. The mechanical Cone Crusher has made improvements in the crushing cavity shape, so that materials can be more fully crushed after entering the crusher, and the crushing efficiency is greatly improved.

The model of this Cone Crusher is XCLA-1800, and its output is 65-100 tons per hour. The feed particle size is less than 60 mm and the discharge particle size is less than 30 mm. The running speed of this Cone Crusher is relatively low, with an average speed of 8-25 rpm.

Technical Reference Data

Model	Maximum feed side length (mm)	Average feed size (mm)		Discharge port adjustment range (mm)		Production capacity (t/h)		Power (kw)		Rotating speed (r/min)	Weight (t)
Model	Maximum feed side length (mm)	Clinker	Limestone	Clinker	Limestone	Clinker	Limestone	Clinker	Limestone	Rotating speed (r/min)	Weight (t)
XCLA-1200	＜100	≤50	≤40	≤5	≤30	10-15	18-30	11	15-18.5	8-25	6.5
XCLA-1600	＜100	≤50	≤50	≤5	≤30	15-25	35-60	15	18.5-22	8-25	9.2
XCLA-1800	＜110	≤50	≤60	≤5	≤30	25-35	65-100	18.5	22-30	8-25	12.6
XCLA-2400	＜125	≤50	≤70	≤5-8	≤30	40-50	120-175	30-37	37-45	4-18	19.8
XCLA-3200	＜150	≤50	≤80	≤5-10	≤30	58-90	150-200	45-55	55-75	3-18	26.5

Equipment Display

High Efficiency Cone Gravel Crusher 22kw To 30kw Limestone Stone Making Equipment

Our Certificate

High Efficiency Cone Gravel Crusher 22kw To 30kw Limestone Stone Making Equipment
