Product Description:
The Double Roller Crusher is a type of industrial roller crusher
that is widely used for crushing a variety of medium and hard
materials like coal, limestone, basalt, etc. This crushing machine
has two toothed rollers that are made of special steels, and
designed to be able to crush materials with an input size of less
than 960mm and an output size of less than 100-400mm. It is
suitable for use in the mining, metallurgy, construction,
quarrying, and other industrial fields. As an industrial roller
crusher, this machine is a heavy-duty toothed roller crusher
machine that is designed to crush materials with great efficiency.
The double roll crusher is capable of producing a high-quality end
product with minimal dust and noise pollution.
Features:
- Product Name: Double Roller Crusher
- Application: Coal, Limestone,basalt, Etc.
- Color: Grey And Yellow
- Capacity: 700-1500TPH
- Input Size: Less Than 960mm
- Power: 160kw*2
- Industrial Roller Crusher: Yes
- Stone Roller Crusher Machine: Yes
- Double Roll Crusher: Yes
Technical Parameters:
| Parameter | Value |
|---|
| Capacity | 700-1500TPH |
| Power | 160kw*2 |
| Model | XCMD1215R |
| Color | Grey And Yellow |
| Application | Coal, Limestone,basalt, Etc. |
| Output Size | Less Than 100-400mm |
| Material | Steel, Manganese Steel And Special Steel |
| Weight | 84t |
| Type | Crushing Equipment |
| Input Size | Less Than 960mm |
| Product Name | Double Roller Crusher |
| Tags | Coal Crushers, Stone Roller Crusher Machine, Double Roll Crusher |
| Model | Diameter of roller (mm) | Length of roller (mm) | Maximum side length of feeding material (mm) | Grain size of discharging material(mm) | Production capacity (t/h) | Power (kw) | Soft connection weight (t) | Direct connection weight (t) |
| XCMD500 | 500 | 1000 | ≤350 | ≤100-200 | 75-150 | 37*2 | 11.5 | 10.2 |
| 1500 | 100-250 | 45*2 | 13.8 | 12.5 |
| 2000 | 150-350 | 90*2 | 16.5 | 14.8 |
| 2500 | 200-500 | 110*2 | 20 | 18.3 |
| XCMD650 | 650 | 1000 | ≤500 | ≤100-300 | 150-350 | 45*2 | 14.3 | 12.5 |
| 1500 | 200-450 | 55*2 | 20.5 | 18 |
| 2000 | 250-550 | 75*2 | 25 | 23 |
| 2500 | 300-650 | 90*2 | 31 | 27 |
| XCMD750 | 750 | 1000 | ≤600 | ≤100-300 | 150-350 | 45*2 | 25 | 23 |
| 1500 | 200-450 | 55*2 | 28.5 | 26.5 |
| 2000 | 250-550 | 75*2 | 32 | 29.2 |
| 2500 | 300-650 | 90*2 | 35.8 | 32.8 |
| XCMD850 | 850 | 1000 | ≤680 | ≤100-300 | 300-650 | 75*2 | 29 | 26.5 |
| 1500 | 400-1000 | 90*2 | 34.5 | 31.5 |
| 2000 | 450-1200 | 110*2 | 39 | 36 |
| 2500 | 500-1500 | 132*2 | 42 | 39 |
| XCMD1000 | 1000 | 1000 | ≤800 | ≤100-300 | 400-750 | 90*2 | 49.8 | 44 |
| 1500 | 500-1200 | 110*2 | 55 | 49.2 |
| 2000 | 550-1500 | 132*0 | 61 | 55.5 |
| 2500 | 650-1800 | 160*2 | 68 | 63 |
| XCMD1200 | 1200 | 1500 | ≤960 | ≤100-400 | 700-1500 | 160*2 | 84 | 76 |
| 2000 | 800-1800 | 185*2 | 96 | 88 |
| 2500 | 1000-2500 | 220*2 | 109 | 101 |
Applications:
BENO XCMD1215R double tooth roller crusher is a heavy-duty coal
crusher specially designed for processing coal, limestone, basalt
and other materials with an input size of less than 960mm. It is
equipped with two 160kw motors and has a total weight of 84t. This
double tooth roller crusher can effectively crush materials with
different hardness, such as coal, limestone, basalt, etc., and
achieve high output efficiency. The roller crusher can be used in
various industries, such as coal mining, coal crushing, building
materials production and other industries. It can also be used for
crushing brittle materials like coal gangue, shale, limestone, and
more. BENO XCMD1215R double tooth roller crusher is a reliable and
efficient coal crusher with a long service life.
FAQ:
Q1: What is the brand name and model number of the Double Roller
Crusher?
A1: The brand name is BENO and the model number is XCMD1215R.
Q2: Where is the Double Roller Crusher produced?
A2: The Double Roller Crusher is produced in Sichuan, China.
Q3: How does the Double Roller Crusher work?
A3: The Double Roller Crusher uses two motors to drive two rollers to
crush materials. The material is fed from the top and is crushed by
the action of the two rollers.
Q4: What materials can the Double Roller Crusher process?
A4: The Double Roller Crusher can process various materials, such as
coal, limestone and other minerals.
